Streaming Apps - HDR | DolbyVision

HDR | DolbyVision

Creative Color & Mix Reviews

**The colorist has done the full HDR color grade and gone through the Dolby Vision trim pass**

For any questions regarding asset delivery for screenings and reviews at internal Netflix facilities, please contact Screening Operations.

dovi_[SHOWNAME]_[CONTENT]_[RANGE]_[COLORSPACE]_[DATE]_

[ASPECT]_[RESOLUTION]_[VERSION]

Example:

dovi_myshow_s01e01_hdr_p3d65pq_20210323_220_3840x2160_ov

CONTAINER: Quicktime MOV

CODEC: Apple ProRes LT

CONTAINER SIZE: Native Deliverable, e.g. 3840x2160 or 1920x1080

PIXEL ASPECT RATIO: 1:1

ACTIVE IMAGE SIZE: Native Deliverable, e.g. 3840x1920 (2.0)

COLOR SPACE: P3

VIDEO RANGE: Legal

WHITE POINT: D65

EOTF: PQ / ST.2084

FRAME RATE: Native Deliverable, e.g 23.976, 24, 25, 29.97, etc

TIMECODE: NON DROP FRAME

Dolby Vision Metadata SIDECAR XML (matching media length)

• XML filename matching with filename of asset

• All file names have to start with the prefix, “dovi_”

Start of File :
1 Second of Black and Silence
Runtime PROGRAMME

1 Second of Black & Silence
: End of File

MIX: NEARFIELD PRINT MASTER

CODEC: Uncompressed Linear PCM

SAMPLE RATE: 48khz

BIT DEPTH: 24 bit

TRACK ORDER:

Option 1

1. 5.1 Left
2. 5.1 Right
3. 5.1 Center
4. 5.1 LFE/SUB
5. 5.1 Left Surround
6. 5.1 Right Surround

OR

Option 2

1. 2.0 Stereo Left or Left Total
2. 2.0 Stereo Right or Right Total

No watermark required

WIP burn-ins if applicable, i.e “Work in Progress"
